The river water quality monitoring station can monitor the real-time water quality status of the river, including temperature, dissolved oxygen, pH value, turbidity, ammonia nitrogen, total phosphorus, total nitrogen and other water quality parameters, making it convenient for people to grasp the water quality status

1. Product Introduction

The LSZ05 pole-type online water quality monitoring station is centered on water quality sensors (water temperature, conductivity, PH, dissolved oxygen, ammonia nitrogen). It monitors and analyzes various water quality parameters and transmits the collected data to the platform to remotely view real-time data and remotely manage equipment. At the same time, it can effectively alarm and intelligently process water quality trends. It can also express the comprehensive index of water quality based on the correlation and combination between real-time water quality parameters, providing customers with a large amount of objective, detailed and effective data, which is of practical significance for solving water pollution problems.

At present, LSZ05 water quality monitoring stations are widely used in aquaculture, sewage treatment, reservoirs, rivers and other places.

2. Product Features

1. Low power collector: static power consumption is less than 50uA

2. Standard GPRS networking, support for extended Bluetooth and wired transmission

3.Support modbus485 sensor expansion

4. Solar charging management MPPT automatic power point tracking

5. 1.5m carbon steel support

6. SMS alarm, send SMS to the designated mobile phone after exceeding the limit

7. ABS material protective box, corrosion-resistant, anti-oxidation, waterproof grade IP66

8. No additional procedures are required, such as wiring, station building, reagent preparation, and personnel post-maintenance. Compared with the national standard water quality monitoring station, it is more convenient to use and install, and the observation data is more intuitive

9. The system can integrate integrated meteorological environment monitoring data

3. System composition

The pole-type online water quality monitoring system is mainly composed of a basic support (including poles, ground cages, ABS anti-corrosion and corrosion-resistant protective box), a power supply system, a monitoring host, water quality sensors, and a cloud platform.

4. Technical Parameters

Serial numbernameMeasuring rangeMeasuring principlemeasurement accuracyIs it standard?Remark

1temperature0~50℃High-precision digital sensor±0.3℃✔

2pH0~14 (ph)Electrochemistry (Salt Bridge)± 0.1PH✔

3ORP-1500mv~1500mvElectrochemistry (Salt Bridge)± 6mv

4Conductivity0~5000uS/cmContact electrode method± 1.5%✔

5Turbidity0~40NTU (low turbidity)Scattered light method± 1%

Low turbidity can be customized

0~1000NTU (medium turbidity)Scattered light method± 1%

Medium turbidity can be customized

0~3000NTU (high turbidity)Scattered light method± 1%

Default

6Dissolved oxygen0~20mg/LFluorescence lifetime method± 2%✔

7Ammonia nitrogen0~100mg/lIon Selective Electrode Method±1mg✔

8cod0~500mg/LUV254 absorption method±5%

The default is hair, cod turbidity integrated; with automatic cleaner to prevent biological attachment and avoid light window pollution to ensure long-term monitoring is still stable; automatic cleaning time and cleaning times can be set, power consumption 0.7W

Turbidity0~400NTUScattered light method± 1%

9Suspended Matter0~2000mg/LScattered light method±5% (depending on sludge homogeneity)

10Chlorophyll0~400ug/LFluorescence methodR2>0.999

Equipped with an automatic cleaner to prevent biological attachment and avoid light window pollution to ensure long-term monitoring stability; the automatic cleaning time and cleaning frequency can be set, power consumption is 0.7W

5. Introduction to Cloud Platform

1.CS architecture software platform, supports direct observation via mobile phone and PC browser, no need to install additional software.

2.Support multiple accounts and multiple devices login

3.Support real-time data display and historical data display dashboard

4. Cloud servers and cloud data storage are stable and reliable, easy to expand, and load balanced.

5.Support SMS alarm and threshold setting

6.Support map display and view device information.

7.Support data curve analysis

8.Support data export in table format

9.Support data forwarding, HJ-212 protocol, TCP forwarding, http protocol, etc.

10. Support data post-processing function

11.Support external running of javascript scripts
